Enclustra’s new Andromeda SoM form factor covers the entire performance spectrum: from compact to high-performance.
Germany, March 15, 2023. FPGA 是许多应用的最佳解决方案。Enclustra公司的FPGA和SoC模块显著降低了这一强大技术的开发工作量和总体拥有成本（TCO）。结合 Enclustra 工程团队长期积累的深厚FPGA 专业知识，许多项目的开发时间可从数年缩短至数月。
FPGAs are conquering more and more application areas, which is no wonder given their enormous parallel performance, flexibility and scalability. From simple interface components to complete systems with integrated ARM processors and multi-gigabit interfaces, the possibilities of FPGAs are virtually unlimited. With a standard FPGA or SoC module, based on an AMD-Xilinx, Intel or Microchip SoC, the entry into FPGA technology is quick and easy. With the design-in kits, Enclustra offers a ready-to-use solution to start any FPGA-based project in just a few minutes.
The technology-specific complexity of FPGAs can be encapsulated with a powerful standard FPGA or SoC module, such as those offered by Enclustra. This makes hardware design even 2
simpler than using a conventional microcontroller or DSP. The use of an FPGA or SoC module is particularly interesting for small and medium production volumes, but can also be attractive for high-volume products.
Don’t reinvent the wheel
FPGA and SoC modules offer many advantages over chip-down designs. The high production volume of off-the-shelf FPGA or SoC modules reduces their cost while providing a proven and reliable solution. Since different pin-compatible modules are available in the same form factor, a product can easily be equipped with a more powerful module even at a late stage of development. Thanks to the high functional density of the FPGA modules, the complexity of the base board is also reduced, making development faster and more cost-effective.
The new Andromeda SoM family: Highest scalability
With the new Andromeda System-on-Module (SoM) product family, Enclustra introduces the next generation form factor. The modular and scalable FPGA system-on-chip (SoC) family supports three sizes: S (40 × 56 mm), M (52 × 66 mm) and L (80 × 64 mm) with 2 to 6 high-performance connectors with up to 780 I/Os.
Two AMD-Xilinx Zynq UltraScale+ MPSoC based modules are already available: The Andromeda XZU65 (Image 1) and the Andromeda XZU90 (Image 2).
Image 1: Andromeda XZU65 – front and back; Small form factor: 68 × 52 mm
The Enclustra Andromeda XZU90 SoM is based on Xilinx’s Zynq UltraScale+ MPSoC. With 686 I/Os, it is optimized for high-performance applications. 3
Image 2: Andromeda XZU90 – front and back; Small form factor: 80 × 64 mm
Three more variants will be available later this year: The Andromeda XZU30 in the compact S form factor, the Andromeda XZU70 (L), and the Andromeda XRU50, based on the AMD-Xilinx ZU48DR RFSoC chip.
Reference design and Linux at your fingertips
Enclustra offers broad design-in support for its products. The detailed documentation, reference designs and application notes make it easy to get started. Schematics, 3D models, PCB footprints and a table with lead lengths complete the offer.
For the creation of a Board Support Package (BSP) based on PetaLinux, Enclustra offers detailed instructions. Also the necessary adjustments for the different boot modes (QSPI, eMMC, SD Card) are explained in detail.
关于 Enclustra GmbH
Enclustra 是一家创新、充满活力、不断发展的 FPGA 设计公司，总部位于瑞士苏黎世，在德国、法国、美国和中国设有子公司。
作为 FPGA 设计和开发领域的领导者，Enclustra 为工业客户和研发机构提供基于 FPGA 的电子模块产品组合和 FPGA 优化 IP 解决方案。与此同时，Enclustra 还在 FPGA 系统设计方面提供领先的工程服务，涵盖基于 FPGA 的系统开发的整个过程：从高速硬件或 HDL 固件到嵌入式软件，从系统设计、规范、实施到原型开发。
Leveraging our expertise in cutting-edge FPGA technology and diverse application knowledge, Enclustra delivers high-performance solutions across various industries, minimizing development effort and accelerating your time-to-market. 4
